LY Super Mini Desktop Fiber Laser Nameplate Marking Machine 20W 30W For Metal Engraver Engraving PVC Plastic Stainless Steel Cartoon Package BSL Software Mobile APP Computer Dual Use 220V 110V

LY Super Mini Desktop Fiber Laser Nameplate Marking Machine 20W 30W For Metal Engraver Engraving PVC Plastic Stainless Steel Cartoon Package BSL Software Mobile APP Computer Dual Use 220V 110V

item ID: 72910
0 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 50 votes, average: 0.00 out of 5
Reviews(0)
USD$1800 USD$1127 (% off)
Payment

Product Detail

Product Tags

LY Super Mini Desktop Fiber Laser Nameplate Marking Machine 20W 30W For Metal Engraver Engraving PVC Plastic Stainless Steel Cartoon

Package BSL Software Mobile APP Computer Dual Use 220V 110V

RE: This machine only 12KG+, save shipping for customers, can put in home/factory or make street marking business by mobile control, have wide applications.



Technical Parameter



Parameters:

Laser power: 20W/30W(Optional)

Laser type: fiber laser

Laser wavelength: 1064nm

Repetition frequency: 30-60KHz

Cooling method: air cooling

Marking range: 110*110mm(20W) / 150*150mm(30W)

Focal distance: 163mm

Marking speed: 7000mm/s

Minimum line width: 0.06mm (depending on material difference)

Minimum character: 0.2mm

Supported formats: PLT/DXF/AI/DST/JPG/GIF/BMP, etc

Lifting method: Manual lifting

Focusing method: Dual red light focusing

Laser: IDD

Galvanometer: ZBTK

Control card: IDD

Field mirror: JGZOE

Power supply: Meanwell

Computer: Not included

Standard configuration: focusing lens, calibration paper, USB flash drive, ruler, positioning bar, hexagonal wrench

Optional: Rotating fixture, smoke purifier

Power supply voltage: 110-220V (5%) 50Hz -60Hz (5%)

Power consumption:≤500W, one and a half hours of electricity

Cartoon size: 470*360*290mm

Weight: 12.3KG ( Without Rotary axis.)
